Equipment application: This product is widely used in hardware baskets, kitchen and bathroom products, lighting products, horticultural wrought iron industry, equipment to replace the traditional straightening and blanking, and then the bottleneck of manual bending, to achieve a job from the original line material to product molding, The ultimate effect can replace 3-5 workers.
The main advantages are low price and stable quality.
Processing wire diameter: 2 - 6mm, 2 - 8mm，2 - 10mm
Name | Spec | Remark |
Processing steel wire（10#steel）Dia.（mm) | Φ2.0-6.0 | |
Total Power(KW) | 6 | |
Voltage | Three phase Any customized voltage-50\60HZh | |
Efficiency | 10-15Piece/Min | Square 300X300mm |
Table size (mm) | 1500*1000*4 | |
Bending Accuracy | ±0.3mm | |
Feeding Accuracy | ±0.3mm | |
Hydraulic maximum cutting diameter (mm) | Φ6 | |
Weight (KGS) | 900 | |
The main machine external dimensions (mm) | 2800*950*1500 | |
Control system | TOPCON CNC | |
Servo | XINJE | |
Bending servo motor power (KW) | 1.5KW | |
Feeding servo motor power (KW) | 2.3KW | |
Max.Feeding speed (m/min) | 120 | |
Largest feed limit | Unlimited | |
Can set the number of files. | 9999999 | |
Cutting way | Top |
